Descrição

• System parameters

• Operation systemLinux

• ROM32 MB

• RAM128 MB

• ProcessadorEmbeded high performance processor

• Display parameters

• Screen size7-inch

• Método de operaçãoCapacitive touch screen

• TipoColorful TFT

• Resolução1024 × 600

• Video parameters

• Lentes/

• Resolução/

• FOV (campo de visão)/

• Wide dynamic range (WDR)/

• Padrão de compactação de vídeoH.265?H.264

• Focal length/

• Audio parameters

• Audio input1 built-in omnidirectional microphone

• Audio compression standardG.711 U?G.711 A?Opus?AAC-LD?AAC-LC?G.726?G.722.1

• Audio output1 built-in loudspeaker

• Taxa de bits de compressão de áudio64 Kbps

• Qualidade de áudioNoise suppression and echo cancellation

• Ajuste de volumeAdjustable

• Capacidade

• Message capacity
  TF card inserted: 200 captured pictures, 200 alarm records
  Without TF card: 2 MB RAM for picture storage; The storage number is decided by the picture size, 200 alarm records

• Notice capacity200

• Linked indoor extensions capacity16

• Linked doorphone capacity17

• Parâmetros de rede

• Network protocolTCP/IP, SIP, RTSP

• Wi-Fi2.4 GHz, IEEE802.11b, IEEE802.11g, IEEE802.11n

• Bluetooth/

• 3G/4G/

• Zigbee/

• Device interfaces

• Entrada de alarme8

• Network interface1 RJ-45 10/100 Mbps self-adaptive

• TAMPER/

• RS-4851 RS-485 (Half duplex)

• USB/

• TF cardSupport TF card, up to 128 G

• Saída de alarme2

• Lock control2 relays, Max. 30 VDC 0.3 A

• Geral

• Botão/

• InstalaçãoWall mounting, table mounting

• Indicador/

• Peso
  Net weight: 355 g (0.8 lb)
  Gross weight: 683 g (1.5 lb)

• Nível de proteção/

• Working temperature-10 °C to 50 °C (14 °F to 122 °F)

• Working humidity10% to 90% (no-condensing)

• Pressão do ar em funcionamento175 mm × 113.5 mm × 21 mm (6.9" × 4.5" × 0.83")

• Bateria/

• Ambiente de aplicaçãoIndoor

• Power consumption≤ 5 W

• IdiomaEnglish, Arabic, French, Russian, Spanish, Spanish (Latin America), Italian, German, Polish, Turkish, Portuguese, Portuguese (Brazil), Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese

• Fonte de alimentação12 VDC, 1 A,IEEE802.3af, Standard PoE
