Descrição

• Entrada de vídeo IP

  64-ch

  Up to 32 MP resolution

  *: The NVR supports up to 8-ch 32/24/16 MP IP video inputs.

• Incoming Bandwidth400 Mbps
• Outgoing Bandwidth400 Mbps
• HDMI 1 Output8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• HDMI 2 Output

  4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

  *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p.

• Saída VGA1920 × 1080/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
• Modo de saída de vídeoHDMI1/VGA simultaneous output, HDMI1/HDMI2 independent output
• CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
• Saída de áudio1-ch, RCA (Linear, 1 KΩ)
• Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input)

• Decoding
• Formato de decodificaçãoH.265+/H.265/H.264+/H.264
• Recording Resolution

  32 MP/24 MP/16MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

  *: The NVR supports up to 8-ch 32/24/16 MP IP video inputs.

• Reprodução síncrona16-ch
• Capacidade de decodificação2-ch@32 MP (30 fps); 3-ch@24 MP (30 fps); 4-ch@16MP (30 fps); 6-ch@12MP (30 fps);10-ch@8 MP (30 fps); 13-ch@6 MP (30 fps);16-ch@5 MP (30 fps);20-ch@4 MP (30 fps);40-ch@1080p (30 fps)
• Dual-Stream RecordingSupport
• Tipo de transmissãoVideo, Video & Audio
• Compressão de áudioG.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2

• Rede
• Conexão remota128
• Protocolo de redeTCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP
• Interface de rede2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces
• Camera Access ProtocolONVIF(Version 2.5), RTSP

• RAID
• RAID TypeN/A

• Interface Auxiliar
• eSATA1 eSATA interface
• SATA4 SATA interfaces
• CapacidadeUp to 16 TB capacity for each disk
• Interface serial2 RS-485 (half-duplex), 1 RS-232
• Entrada/saída de alarme16/9
• Interface USBFront panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0
• Ctrl 12V

  Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.

  *: The Ctrl 12V power is controlled by alarm output 9.

• DC 12V12 VDC, 1 A power output

• Geral
• Fonte de alimentação100 to 240 VAC, 50 to 60 Hz
• Consumo≤ 15 W (without HDD)
• Temperatura de funcionamento-10 °C to 55 °C (14 °F to 131 °F)
• Umidade de funcionamento10% to 90%
• Chassi19-inch rack-mounted 1.5U chassis
• Dimensões (L×P×A)445 × 400 × 75 mm ( 17.5"× 15.7" × 3.0")
• Peso≤ 5 kg (without HDD, 11 lb.)

• Certificação
• FCCPart 15 Subpart B, ANSI C63.4-2014
• CE

  EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201

  9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020
